Simon Altair IYF
Simon Altair IYF Istanium LED urban decorative luminaire made of die-cast aluminium, with post-top fastening by means of two Y-shaped arms. It provides the necessary public lighting with maximum energy efficiency: light flux from 1,830 lm, efficiency up to 141 lm/W and guaranteed thermal management.
)
Compact luminaire with a flat cover and an internal LED cooling system with a honeycomb design and no visible fins. Access and maintenance are carried out via the top part, fastened with four captive screws that are invisible when installed. The electro-optic group is removable and upgradeable by means of a single piece, enabling instant updates of the luminaire.
)
)
Compact luminaire with a flat cover and an internal LED cooling system with a honeycomb design and no visible fins.
)
)
2N- with dimming without control line; self-regulation
The luminaire's electronic driver has a programmed timer that reduces power by half after 4.5 hours from switch-on.
1N- without dimming
The electronic driver delivers 100% of the power with no option to be dimmed. If there is any fluctuation in the line voltage, the device compensates the supply current of the Istanium LED modules to maintain the luminous flux (input voltage from 208 to 277 Vac). Likewise, if the electrical cabinet has a headline flux dimming equipment, the driver will not dim the lamp (an Istanium LED luminaire with CAD dimming is required).
