Systimax® RJ45 IT connector category 5e UTP graphite

Systimax® RJ45 IT connector category 5e UTP graphite

REFERENCE NO.: 75542-32

R.P.: Price on request

PACKAGING: 10Units

Variables de unidades de obras ---> -false-false

Systimax RJ45 IT connector black front view


This image represents the combination of different references

Systimax RJ45 IT connector black packaging


SERIES: Simon 75 FORMAT: RJ CONNECTOR TYPE: RJ45 TYPE: UTP CHECK: Category 5e FINISH: Black COMPATIBLE SERIES: Simon 82 Detail Simon 82 Nature Simon 82 Simon 82 Centralizations Simon 27 Play Simon 27 Neos Simon 27 Simon 27 Scudo Simon 31 Simon 44 Aqua Simon 73 Loft Simon 88 Plates

82005-30

82005-31

82005-33

82005-34

82005-38

82005-93

Product description

RJ45 systimax ® computer connector Type 5e UTP finished in graphite colour, which you will be able to buy in the Simon 75 series, the type of terminal connection and the operation is by insertion. Manufactured with the highest quality metal components with halogen-free thermoplastic insulation that allow you to comply with the regulation TIA 568 C. 2 and in addition operation at temperature intervals that comprise 5ºC and 40ºC. Enjoy with multiple color combinations, a wide range for all kinds of decorative spaces, so that you can not resist even a single corner of your home, it plays with the shapes, thanks to the rectangular design of the trim frame, allows you to adopt two different shapes with different aesthetics. The best if you have varied tastes. As for the compatibility with the mechanisms of the Simon 77 series, it is an open door to the world of simplicity in installation, without the need to use additional tools or strip cables, simply insert and squeeze and enjoy the element you wanted in your home correctly functional.

BASIC INFORMATION

Series: Simon 75

Finish: Black

Format: RJ

Check: Category 5e

Type: UTP

Connector type: RJ45

Number of connectors: 1

Type of terminal connection: Insertion

Type of mechanism: Insertion

Compatibility: Simon 27 Play, Simon 27 Neos, Simon 27 Scudo, Simon 27, Simon 31, Simon 44 Aqua, Simon 75, Simon 82 Detail, Simon 82 Nature, Simon 82 and Simon 88 frames

Packaging contents: Systimax RJ45 connector

TECHNICAL INFORMATION

IP rating: 20

Number of contacts: 8

Number of wires: 8

Manufacturing material: Metallic components with halogen-free thermoplastic insulation

Type of product: Standard

Market available: CE

REGULATIONS

Regulations: Directive 2011/65/UE RoHS + EN 50581:2012 + IEC 60603-7-2 Ed 2.0

INSTALLATION AND MAINTENANCE

Installable in flush mount junction box: Universal

Operating temperature range: 5 to 40 ºC

Storage temperature range: -25 to 50 ºC

LOGISTIC DATA

Available in display box: Yes

Packaging quantity: 10

Box measurement unit: MM

Height: 82.000

Wide: 83.000

Depth: 223.000

Box volume: 1517738.000

Box volume measurement unit: MMQ

Net weight of box: 0.180

Unit weight of box: KGM

EAN code: 8421053045176

Available in multiple box: No

Multiple box measurement unit: MM

Multiple box packaging quantity measurement unit: UN

Multiple box volume measurement unit: MM3

Unit weight of multiple box: KG

Available on pallet: No
