Set of 2 2-way switches 10AX 250V~ with fast terminal connection system

Set of 2 2-way switches 10AX 250V~ with fast terminal connection system

REFERENCE NO.: 75397-39

R.P.: Price on request

PACKAGING: 10Units

Variables de unidades de obras ---> -false-false

Set 2 2-way switches 10AX 250V~ front view


This image represents the combination of different references


Set 2 2-way switches 10AX 250V~ rear view

Set 2 2-way switches 10AX 250V~ packaging


SERIES: Simon 75 INTENSITY: 10 AX TYPE OF TERMINAL CONNECTION: Fast TYPE OF MECHANISM: Pivoting COMPATIBLE SERIES: Simon 82 Concept Simon 82 Detail Simon 82 Nature Simon 82 Simon 75 Rockers

82026-30

82026-31

82026-33

82026-34

82026-38

82026-93

Product description

This pack of Simon is a group comprising 2 2-way switches for currents of up to 10A and 250 volts, of the Simon 75 series. It is an ideal kit if what you are looking for is interrupted a current of a circuit or deflect. The 2-way switch stands out for having a quick terminal connection. Its installation is very simple and offers two possibilities, kit it by flush mounting or directly mounting on the surface or wall. Note that the mechanism does not have latching, so it requires a control device. Simon stands out for the quality of its products thanks to the materials used for its manufacture. In this case the 2-way switches are made with metal components with thermoplastic insulation free of halogens. These elements give the product a lot of resistance and make it to work optimally low temperatures very high or very high, by doing so capable of withstanding from -25 degrees up to + 50 degrees centigrade.

BASIC INFORMATION

Indicator function: No

No. of possible elements: 1 element

Claw: Simon 27

Compatibility: Simon 75, Simon 82 Detail, Simon 82 Nature, Simon 82 and Simon 88 frames

Packaging contents: Mechanism

Series: Simon 75

Version: Double

Intensity: 10 AX

Voltage: 250 V~

Type of terminal connection: Fast

Type of mechanism: Pivoting

TECHNICAL INFORMATION

Cable section admitted: From 1.5 to 2.5 mm

Cable stripping necessary: 11 mm

IP rating: 21

Manufacturing material: Metallic components with halogen-free thermoplastic insulation

Type of product: Standard

Market available: CE

REGULATIONS

Regulations: Directive 2014/35/UE LVD + Directive 2011/65/UE RoHS + EN 50581:2012 + EN 60669-1:1999 + EN 60669-1:1999 A1:2002 + EN 60669-1:1999 A2:2008

INSTALLATION AND MAINTENANCE

Installation type: Suitable for surface and flush mounting

Installable in flush mount junction box: Universal

Operating temperature range: 5 to 40 ºC

Storage temperature range: -25 to 50 ºC

LOGISTIC DATA

Available in display box: Yes

Packaging quantity: 10

Box measurement unit: MM

Height: 83.000

Wide: 165.000

Depth: 221.000

Box volume: 3026595.000

Box volume measurement unit: MMQ

Net weight of box: 0.680

Unit weight of box: KGM

EAN code: 8421053003985

Available in multiple box: Yes

Multiple box packaging quantity: 50

Multiple box measurement unit: MM

Multiple box packaging quantity measurement unit: ZCM

Height of multiple box: 223.000

Width of multiple box: 172.000

Depth of multiple box: 430.000

Multiple box volume: 16493080.000

Multiple box volume measurement unit: MMQ

Net weight of multiple box: 3.400

Unit weight of multiple box: KGM

Multiple box EAN code: 8421053040553

Available on pallet: No
